NE150
NE150 consists of rotating platform, walking device, working device, power, hydraulic pressure, electric control, braking and other systems. The motor is used to match the lithium battery, which is energy-saving and environmentally friendly, and the power system is optimized to meet the requirements of efficient operation
TECHNICAL SPECIFICATIONS
Operating Weight | 13,900 KG |
Bucket Capacity | 0.5~0.7 m3 |
Max. Travel Speed | 5.3 km/h |
Dimension (LxWxH) | 7750 x 2500 x 2760 mm |
Max. Digging Reach | 8197 mm |
Max. Digging Depth | 6039 mm |
Max. Digging Height | 8651 mm |
Motor Rated Power | 92 kW @ 2,000 rpm |
Battery Type | Lithium Battery |
Battery Capacity | 210 kWh |
Battery Voltage |
